Quick Details

  • Place of Origin: Guangdong, China (Mainland)
  • Brand Name: ASRAM
  • Model Number: ASR-DIP-OF-P16-2796
  • Usage: Outdoor, advertising
  • Tube Chip Color: Full Color
  • Display Function: Video
  • Pixels: P16
  • Screen Dimension: Customized Size
  • Color: Full color
  • Brightness: 8000cd/m2
  • Viewing distance: 14-300m
  • Warranty: 2years
  • LED configuration: 2R,1G,1B
  • Gray Scale: >4906
  • Power: Average:320w/sqm
  • Waterproof: IP67
  • Life span: 100000hours

Packaging & Delivery

Packaging Details 1.anti-shaking wood case
2.air freight case
3.anti-static freight case
Delivery Time 5 days
P16 full color led display outdoor .HD video led screen advertising



Led display outdoor Specification:

Display and control feature Structure feature
SpecificationParameterSpecificationParameter
Pixel Pitch16 mmModule size256 mm*256mm
Pixel composing2R1G1BDisplay resolution16 *8 pixel
Wavelength ®620-630nmStandard cabinet size1280 mm*960 mm
Wavelength (G)520-535nmWeight per sqm65 Kg/sqm
Wavelength (B)465-475nmProtection classificationIP65
Wave Angle (H)110°(H)/ 60°(V)Install modeWallmount, hung and stand structure
LED packageDIP546Cabinet MaterialIron/Aluminum
Density per sqm2500 pixelWorking power
Display color256*256*256SpecificationParameter
Whiteness brightness≥7500Working voltageAC 220v/380v±10% 47~64Hz
Brightness level128 gradeMax power/sqm750W/sqm
Changing frame frequency60 HzAverage power/sqm320W/sqm
Refresh400 HzShort circuit protectionYes
Driving methodConstant StaticLed Lamp typeRed:Opto Blue:Silan Green:Silan
Control modesynchronousWorking environment
Display portDVISpecificationParameter
Display mode1024*768 /1024*1024EnvironmentOutdoor
Out of control1/10,000 ( scattered)Working temperature-20~60°C
lifetime100,000 hoursWorking Humidity10~90%





Led display outdoor Factory:




Effect:





Applications:



Comercial advertising led display outdoor, Stadium perimeter led display outdoor,Mobile trailer led display outdoor module,  for mobile media,shopping mall led display outdoor for logo showing,bank&stock exchange led display outdoor for rates showing, train & bus   led display outdoor, air port led display outdoor , telecommunication led display outdoor system for information showing and instruction.







  We offer you a possibility to run commercials on our screens which are unique advertising media that combine the advantages of outdoor and TV advertising. This kind of advertising is extremely important if you want to create and support one's company image or a product for the sales encouragement. There are many sizes for selection: outdoor, indoor display screens, semi outdoor screens. And also there are full color, dual color and single color for your selection. Customer's design size is acceptable.

Asram Display CO.,LTD is professional in the research and manufacturing of LED Display Screen, which is came into being and grew with the development of information technology. It’s well ahead of the LED display industry with the advantages of longer life span and high efficient of photoelectric conversion, etc. Meanwhile, it’s popular and widely used in daily life, such as finance, securities, stations, airports and supermarkets as the result of the digital-to-analog conversion; also it’s necessary for the live program in the stadium, especially for the direction in highway, that is significant to drivers; to the live show; parties and advertisement, it’s a visual revolution. All the examples show that LED Display is indispensable to wherever the life, work or entertainment.


led display outdoor Package:



led display outdoor Installation:



If interested, Welcome your inquiry! (Factory:Shenzhen,China)



Tel:86- 755- 2956 8603

Skype:sunnydfx
